Audyssey MultEQ XT Sound Correction Results

The time and frequency response of your sound system has been calibrated using Audyssey MultEQ XT sound equalization technology. Your system has been measured at 10 listening positions to create optimal sound performance.

PRINTING INSTRUCTIONS:   You may print out this certificate now or do it later using the Audyssey Installer Web Site, which stores all of your certificates (see the Installation Manual for details). To print this correctly, please set your printing margins to their minimum values. From this browser menu, open the File menu, and select Page Setup. Enter 0 for all 4 margins, and your browser will automatically adjust them to their minimum values. NOTE: This message will not appear on your certificate.
Audyssey MultEQ XT Sound Correction Results
  Before MultEQ XT     After MultEQ XT
Left Front

Speaker Settings: Distance (ft): 11,2; Trim (dB): -5,5;
Crossover (Hz): 60

Center

Speaker Settings: Distance (ft): 10,6; Trim (dB): -8,5;
Crossover (Hz): 80
Right Front

Speaker Settings: Distance (ft): 11,2; Trim (dB): -6,5;
Crossover (Hz): 60

Right Surround

Speaker Settings: Distance (ft): 8,400001; Trim (dB): -5,5;
Crossover (Hz): 80
Left Surround

Speaker Settings: Distance (ft): 8,400001; Trim (dB): -6,5;
Crossover (Hz): 80

Main Subwoofer

Speaker Settings: Distance (ft): 12,2; Trim (dB): -2;
